Pure PEX-A Piping System

Not all pipes are created equal.

The World’s First, Best and Most Widely Used.

Join the global trend towards Uponor Pure PEX-A piping systems.

Uponor Black Couplings - Afripex Piping Systems - Pex A pipe, fittings and expansion. Pure PEX Pipe.

Applications:

  • Suitable for over 400 different types of fluids
  • Perfect for hot and cold drinking water
  • Perfect for water based heating and cooling applications, eg underfloor heating (oxygen barriered version)
  • New builds
  • Renovations

Specifications:

  • 16 to 75mm using the Q&E connection system
  • 90 to 110 using Wipex jointing
  • 125 to 160 using electrofusion fittings and jointing
  • Available in PN6 and PN10
  • Intended for tap water systems with a continuous operating temperature of maximum 70 °C (instantaneous maximum 95 °C). Operating pressure maximum 10 bar (1 MPa)
  • Available plain and with oxygen barrier
  • Available in bars and coils

Features:

  • 100+ year design life
  • 15 year manufacturer warranty
  • Designed for fast installation
  • Does not give off taste, odour, heavy metals or leach chemicals
  • Has latest European drinking water certification
  • No theft value
  • Self-sealing joint
  • No crimps, internal sleeves, solder, nuts etc.
  • No tool calibrating
  • No heating of the joint
  • System cannot be cannibalised
  • Simplest jointing system available
  • Easy visual inspection of joints
  • Long lengths
  • Fewer joints
  • Lightweight
  • Flexible
  • Repairable
  • Thermally insulative
  • Not form stable
  • Heat moulded
  • Manifolds
  • 100% recyclable

Benefits:

  • The plumbing will last the life of the concrete structure
  • Peace of mind for the system owner
  • Save up to 2/3 of your installation labour cost
  • Safe, beautiful, hygienic drinking water
  • Benefit from ongoing and current research into what is safe for consumption. Old standards are improved for good reason.
  • Greater profitability
  • Improved safety on construction sites
  • Only system available which does not rely on the installer to close the joint – meaning greatly reduced risk of joint failure.
  • Hugely reduced scope for installation failure
  • No risk of system failure due to over/under heating the joint
  • Risk of installation being contaminated with non compliant product, is eliminated
  • Fastest installation, reduced skills level for competent installation
  • This is the only piping system where you can easily visually check if the joint has been correctly done or not.
  • Fewer joints (cost saving), faster installation (cost saving)
  • Reduced opportunity for leaks
  • Easy to transport (labour cost effective)
  • Fewer elbows (cost saving), reduced pressure loss, reduced chance of kinking
  • Kinks are quickly and easily 100% self healed with the application of heat, thus ensuring long runs maintain their integrity.
  • Naturally more energy efficient
  • Can be conduited, thus enabling damaged pipe to be replaced without having to chase holes eg. To repair hole drilled into pipe.
  • With the application of heat, Pex-A can be bent into shapes, which hold their form when the pipe is cooled.
  • Enable serviceable installations with conduits. Provide single access point for single quality isolating valve.
  • We are all about sustainable use of resources. Our latest product, Aqua Blue, has a reduced CO2 footprint of up to 90% compared to fossil based pex pipes on the market.
Pex pipe installation guide - Afripex Piping Systems - Pex A pipe, fittings and expansion. Pure PEX Pipe.

Quick & Easy Jointing Technology

The Q&E fitting is a jointing concept that relies on the unique elastic features of PEX-A pipe to create a joint that is stronger than the pipe itself. The unique shape memory of PEX-A piping forms a tight seal around the fitting creating a strong reliable connection within seconds.

Specifications:

  • 16 to 75mm
  • In high performance PPSU and threaded Dr brass
  • Intended for tap water systems with a continuous operating temperature of maximum 70 °C (instantaneous maximum 95 °C). Operating pressure maximum 10 bar (1 MPa)

PEX and PPSU Fittings

Feature:

  • 15 year manufacturer warranty
  • Designed for fast installation
  • Has latest European drinking water certification
  • PPSU has no theft value
  • Self sealing joint
  • No crimps, internal sleeves, solder, nuts etc.
  • No tool calibrating
  • No heating of the joint
  • System cannot be cannabilised
  • Simplest jointing system available
  • Easy visual inspection of joints
  • 100% Recyclable

Benefits

  • Peace of mind for the system owner
  • Save up to 2/3 of your installation labour cost
  • Benefit from ongoing and current research into what is safe for consumption. Old standards are improved for good reason.
  • Greater profitability
  • Improved safety on construction sites
  • Only system available which does not rely on the installer to close the joint – meaning greatly reduced risk of joint failure
  • Hugely reduced scope for installation failure
  • No risk of system failure due to over/under heating the joint
  • Risk of installation being contaminated with non compliant product, is eliminated
  • Fastest installation, reduced skills level for competent installation
  • This is the only piping system where you can easily visually check if the joint has been correctly done or not.
  • We are all about sustainable use of resources

Downloadable Files

Uponor Quick and Easy Jointing Technology - Afripex Piping Systems - Pex-A Pipes

Download

Uponor Quick & Easy Jointing Technology

Uponor Pex Technical Information - Afripex Piping Systems - Pex A pipe, fittings and expansion. Pure PEX Pipe.

Download

Uponor Pex Technical Information

Afripex Product List Q&E Shrink-Fit - Piping Systems

Download

Afripex Product List Excluding Pre-Insulated

Pure PEX-A Piping System Videos
